Technical Advantages
- Using single-tube IGBT high-frequency inverter technology, the output power is large, stable and reliable.
- Wire detection function, dry extension length 20mm, easy to start arcing.
- Current/Voltage digital display preset function, easy to match welding parameters.
- Flux cored welding/Gas shielded welding/Stick welding three-purpose function setting, constant current/constant voltage output.
- Built-in hand welding VRD anti-shock function.
- Arc hardness adjustment, suitable for different materials and process requirements.
- Applying leading anti-splash control circuit, the splash is small, the molding is uniform and beautiful.
- Good arc ignition reliability, suitable for fast spot welding.
- Especially suitable for thin plate welding, the thinnest 0.5mm does not wear.
- 0.8mm Welding stick sheet has excellent spot welding performance.
Technical Parameter
| Model | MIG-350 | MIG-400 |
| Voltage range (V) | 3-Phase 380±15% 50/60HZ | |
| Rated input power (KVA) | 13.8 | 15.9 |
| Rated input current (A) | 22 | 27 |
| No-load voltage (V) | 78 | 80 |
| Current adjustment range (A) | 60-350 | 60-400 |
| Voltage adjustment range (V) | 15.7-31.5 | 15.7-31.5 |
| Wire feeding speed (m/min) | 18 | |
| CO2 gas flow (L/min) | 15-20 | |
| Weld stick (mm) | 0.8-1.2 | 0.8-1.2 |
| Rated load duration (%) | 60 | |
| Weight (Kg) | 27 | |
| External dimensions (mm) | 540*310*560 | |
| Remark: 3~220V/415V/440V can be customized | ||
