Technical Advantages
- Using single-tube IGBT high-frequency inverter technology, the output power is large, stable and reliable.
- Wire detection function, dry extension length 20mm, easy to start arcing.
- Current/Voltage digital display preset function, easy to match welding parameters.
- Built-in hand welding VRD anti-shock function.
- Arc hardness adjustment, suitable for different materials and process requirements.
- Applying leading anti-splash control circuit, the splash is small, the molding is uniform and beautiful.
- Good arc ignition reliability, suitable for fast spot welding.
- Especially suitable for thin sheet welding, the thinnest 0.5mm no burn-through.
- Excellent spot welding performance esp for 0.8mm Welding stick sheet .
Technical Parameter
| Model型号 | MIG-120A(1kg) | MIG-120B(1kg) |
| Voltage range (V) | 1-Phase220±15% 50/60HZ | 1-Phase220±15% 50/60HZ |
| Rated input power (KVA) | 3.2 | 3.2 |
| Rated input current (A) | 24.4 | 24.4 |
| No-load voltage (V) | 55 | |
| Welding current range(A) | 40-120 | 50-120 |
| Working voltage range (V) | 16-20 | 16.5-20 |
| Weld wire (mm) | 0.8-1.0 | 0.8-1.0 |
| Weld rod(L/mm) | 2.0-3.2 | 2.0-3.2 |
| Rated load duration (%) | 40 | |
| Flux cored wire | 1KG | 1KG |
| Weight (Kg) | 3.5 | 3.2 |
Product Accessories
